AOC FDR

AOC QSFP+ FDR 56Gb/s

The Infiniband QSFP+ is a monolithic optoelectronic Active Optical Cable assembly containing four complete fiber optic transceivers per end, each operating at data rate of 14Gbps and supporting a reach up to 100 meters.

This integrated cable solution provides low cost reliable transport for aggregated data rates up to 56,1Gbps (4X14.025Gbps)

Features

• Full duplex 4 channel parallel active optical cable
• Transmission data rate up to 14Gbps per channel
• SFF-8661 QSFP+ compliant housing and hot pluggable electrical interface
• Compliant to the SFF-8685 Standard
• Implements all optional and required functionality of the Infiniband specification
• 0…70°C operating temperature range
• 3.3 V power supply
• Variable cable node to node length available up to 100m
• Low power consumption less than 1W per node (equivalent ~ 15pJ/bit)

General Applications

• Infiniband interconnections in Data Centers, HPC and Supercomputers
